30kw 50kw Single Axis Solar Tracking System 2m Auto Sun Tracking Solar Panel

Name: 30kw 50kw Single Axis Solar Tracking System 2m Auto Sun Tracking Solar Panel
Brand: Good Future Solar
Price: 1 USD

China 30kw 50kw Single Axis Solar Tracking System 2m Auto Sun Tracking Solar Panel factory

Brand Name : Good Future Solar

Model Number : MG/ZG/YG/JG.ETC SOLAR SYSTEM

Certification : CE/ISO/BV/SGS

Place of Origin : China

MOQ : Negotiate

Price : Negotiate

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 1000MW per Month

Delivery Time : 30 Working Days after design confirm

Packaging Details : Neutral packing

Product : 30kw 50kw Single Axis Solar Tracking System 2m Automatic Sun Tracking Solar Panel

Driving System : Slew drive

Tracking Range : ±60 degree

String-Powered : Yes

Night Position : Yes

Tracking Accuracy : ≤ 1°

Operation Temperature : -40℃ - 70℃

Module Supported : All commercially available modules

Contact Now

30kw 50kw Single Axis Solar Tracking System 2m Automatic Sun Tracking Solar Panel

Working principle:

The solar tracker uses high-precision astronomy algorithm to calculate the angle of the sun,
combined with high-performance microcontroller (DSP core), making the system accurate
and reliable, not rainy days interference,using international first-line brand tilt sensor, real-time
closed-loop feedback tracking angle, automatic tracking, without human intervention.

Functions:

1) It can respond to site features and changing weather conditions, and conditions to continuously optimizing the tracking algorithm of each individual row, to make boost solar power system production.
2) The most promising product technology trends in solar today. which help users get more power generated.
3) Simple structure ,easy in installation and debugger application.

Technical Parameters of single axis solar tracker

Single Axis Solar Tracking System 2m Automatic Sun Tracking Solar Panel
Tracking Range	士 60°
Driving System	Slew drive, 28VDC motor
Modules per Tracker	Max.90 modules per tracker
System Voltage	1000 V or 1500 V
Ground Coverage Ratio	≥ 25%
Power Consumption	0.2-0.5kWh/day
Power Supply Mode	Powered by PV strings, back-up lithium battery
Standard Design Wind Speed	18m/s
Module Supported	All commercially available modules
Operation Temperature	-40℃ - 70℃
Control Algorithm	Astronomical algorithms + Tilt sensor close loop
Tracking Accuracy	≤ 1°
String-Powered	Yes
Backtracking	Yes
Communication Options	LoRa wireless /RS 485 cable
Night Position	Yes

30kw 50kw Single Axis Solar Tracking System 2m Auto Sun Tracking Solar Panel
